Redis Beyond Caching: Patterns You Should Know

Everyone knows Redis as a cache. Stuff data in, get it out fast. But Redis can do way more.

Ive used Redis for job queues, rate limiting, leaderboards, session storage, real-time messaging, and distributed locks. Lets explore the patterns that actually matter.

Redis Data Structures Overview

1. Pub/Sub for Real-Time

When you need to broadcast messages across servers:

import { createClient } from 'redis';

const publisher = createClient();
const subscriber = createClient();

await publisher.connect();
await subscriber.connect();

// Subscribe to channel
await subscriber.subscribe('notifications', (message, channel) => {
  console.log(`Received on ${channel}: ${message}`);
});

// Publish from anywhere
await publisher.publish('notifications', JSON.stringify({
  type: 'order_created',
  orderId: '12345',
  userId: 'user_abc'
}));

Use cases:

WebSocket scaling (see my WebSocket post)
Cache invalidation across servers
Real-time notifications

Limitation: Messages are fire-and-forget. If no one is listening, the message is lost.

2. Sorted Sets for Leaderboards

Sorted sets keep elements ranked by score. Perfect for leaderboards:

const redis = createClient();

// Add scores
await redis.zAdd('leaderboard', [
  { score: 1500, value: 'player1' },
  { score: 2300, value: 'player2' },
  { score: 1800, value: 'player3' },
]);

// Get top 10
const top10 = await redis.zRange('leaderboard', 0, 9, { REV: true });
// ['player2', 'player3', 'player1']

// Get player rank (0-indexed)
const rank = await redis.zRevRank('leaderboard', 'player1');
// 2 (third place)

// Get player score
const score = await redis.zScore('leaderboard', 'player1');
// 1500

// Increment score
await redis.zIncrBy('leaderboard', 100, 'player1');
// player1 now has 1600 points

Use cases:

Gaming leaderboards
Top posts/content
Rate limiting windows
Priority queues

3. Rate Limiting with Sliding Window

Fixed windows have edge cases. Sliding window is better:

async function isRateLimited(
  userId: string,
  limit: number,
  windowSeconds: number
): Promise<boolean> {
  const key = `ratelimit:${userId}`;
  const now = Date.now();
  const windowStart = now - (windowSeconds * 1000);

  // Remove old entries
  await redis.zRemRangeByScore(key, 0, windowStart);

  // Count requests in window
  const count = await redis.zCard(key);

  if (count >= limit) {
    return true; // Rate limited
  }

  // Add new request
  await redis.zAdd(key, { score: now, value: `${now}` });
  await redis.expire(key, windowSeconds);

  return false;
}

// Usage: 100 requests per minute
if (await isRateLimited(userId, 100, 60)) {
  throw new Error('Too many requests');
}

4. Distributed Locks

When only one process should run something:

async function acquireLock(
  lockName: string,
  ttlSeconds: number
): Promise<string | null> {
  const lockId = crypto.randomUUID();
  const key = `lock:${lockName}`;

  // SET NX = only set if not exists
  const acquired = await redis.set(key, lockId, {
    NX: true,
    EX: ttlSeconds
  });

  return acquired ? lockId : null;
}

async function releaseLock(lockName: string, lockId: string): Promise<boolean> {
  const key = `lock:${lockName}`;

  // Only delete if we own the lock (Lua script for atomicity)
  const script = `
    if redis.call("get", KEYS[1]) == ARGV[1] then
      return redis.call("del", KEYS[1])
    else
      return 0
    end
  `;

  const result = await redis.eval(script, {
    keys: [key],
    arguments: [lockId]
  });

  return result === 1;
}

// Usage
const lockId = await acquireLock('process-orders', 30);
if (lockId) {
  try {
    await processOrders();
  } finally {
    await releaseLock('process-orders', lockId);
  }
} else {
  console.log('Another process is already running');
}

Important: Always use TTL to prevent deadlocks if a process crashes.

5. Session Storage

Redis is great for sessions - fast, shared across servers, auto-expiring:

interface Session {
  userId: string;
  email: string;
  roles: string[];
  createdAt: number;
}

async function createSession(sessionId: string, data: Session): Promise<void> {
  await redis.hSet(`session:${sessionId}`, {
    userId: data.userId,
    email: data.email,
    roles: JSON.stringify(data.roles),
    createdAt: data.createdAt.toString()
  });
  await redis.expire(`session:${sessionId}`, 86400); // 24 hours
}

async function getSession(sessionId: string): Promise<Session | null> {
  const data = await redis.hGetAll(`session:${sessionId}`);

  if (!data.userId) return null;

  return {
    userId: data.userId,
    email: data.email,
    roles: JSON.parse(data.roles),
    createdAt: parseInt(data.createdAt)
  };
}

async function refreshSession(sessionId: string): Promise<void> {
  await redis.expire(`session:${sessionId}`, 86400);
}

6. Streams for Event Sourcing

Redis Streams are like Kafka-lite. Great for event logs:

// Produce events
await redis.xAdd('orders', '*', {
  event: 'order_created',
  orderId: '12345',
  userId: 'user_abc',
  total: '99.99'
});

// Consume events (blocking read)
const events = await redis.xRead(
  { key: 'orders', id: '$' }, // $ = only new messages
  { BLOCK: 5000, COUNT: 10 }
);

// Consumer groups for distributed processing
await redis.xGroupCreate('orders', 'notification-workers', '0', { MKSTREAM: true });

// Read as part of consumer group
const messages = await redis.xReadGroup(
  'notification-workers',
  'worker-1',
  { key: 'orders', id: '>' },
  { COUNT: 10 }
);

// Acknowledge processed messages
await redis.xAck('orders', 'notification-workers', messageId);

When to use Streams vs Pub/Sub:

Pub/Sub: Fire and forget, no persistence
Streams: Need message history, consumer groups, acknowledgment

7. Caching Patterns

Since were talking Redis, lets cover caching patterns too:

// Cache-aside pattern
async function getUser(userId: string): Promise<User> {
  const cached = await redis.get(`user:${userId}`);
  if (cached) {
    return JSON.parse(cached);
  }

  const user = await db.users.findById(userId);
  await redis.set(`user:${userId}`, JSON.stringify(user), { EX: 3600 });

  return user;
}

// Write-through pattern
async function updateUser(userId: string, data: Partial<User>): Promise<User> {
  const user = await db.users.update(userId, data);
  await redis.set(`user:${userId}`, JSON.stringify(user), { EX: 3600 });
  return user;
}

// Cache invalidation
async function invalidateUser(userId: string): Promise<void> {
  await redis.del(`user:${userId}`);
}

Quick Reference

| Pattern | Data Structure | Use Case | |---------|---------------|----------| | Caching | Strings/Hashes | Speeding up reads | | Rate Limiting | Sorted Sets | API throttling | | Leaderboards | Sorted Sets | Rankings, top-N | | Real-time | Pub/Sub | WebSocket scaling | | Event Logs | Streams | Event sourcing | | Sessions | Hashes | User sessions | | Locks | Strings + NX | Distributed locking | | Queues | Lists | Simple job queues |
